SG BioVision 2000 Trinocular Laboratory Microscope (BSG003-2025)

The SG BioVision 2000 is a professional laboratory microscope equipped with infinity plan
objectives, advanced focusing system, and precision mechanical stage, suitable for universities,
hospitals, and research laboratories.

Key Features
• Trinocular head, 30° inclined, 360° rotatable, IPD 52–75 mm
• WF10X/20 mm eyepiece, high eye-point (21 mm)
• Infinity Plan objectives:
– 4X/0.10 (WD 13.21 mm)
– 10X/0.25 (WD 5.03 mm)
– 40X/0.65 (WD 0.72 mm)
– 100X/1.25 oil (WD 0.17 mm)
• Backward quadruple nosepiece
• Double-layer mechanical stage 156×138 mm, travel 76×54 mm
• Coaxial coarse/fine focus; fine division 0.001 mm
• Abbe NA 1.25 condenser (phase-slide compatible)
• 6V 20W halogen lamp, Köhler illumination
• Power: 100–240V

Lead Time
1 month
