SG BasicLab Entry Biological Microscope (BSG001-2025)

The SG BasicLab Biological Microscope is designed for entry-level laboratory, school, and
training applications. It provides bright, clear optical performance with standard achromatic
objectives and smooth mechanical operation.

Key Features
• Binocular head, 30° inclined, interpupillary distance 55–75 mm
• WF10X/18 mm eyepieces
• Achromatic 4X, 10X, 40X (spring), 100X (spring, oil)
• Quadruple revolving nosepiece
• Double-layer mechanical stage (110×126 mm), travel 70×30 mm
• Coaxial coarse & fine focusing, 0.002 mm fine scale
• Abbe NA 1.25 condenser with iris & filter holder
• Incandescent illumination: 20W (110V/220V)

Optional Accessories
• Eyepieces: WF16X, WF20X
• Objectives: Achromatic 20X, Achromatic 60X (spring)
• LED illumination module

Lead Time
1 month
